Copeland 120,000 BTU/Hr Medium/High Temp. Discus Compressor | 208-230/3

SKU #:3DPHR12ME-TFC-800-CPDMFG #:3DPHR12ME-TFC-800

Copeland 120,000 BTU/Hr Medium/High Temp. Discus Compressor | 208-230/3

SKU #:3DPHR12ME-TFC-800-CPDMFG #:3DPHR12ME-TFC-800

$ / EA

Description

3 Cylinder 120,000 BTU/Hr Nominal Capacity Medium/High Temperature Semi-Hermetic Discus Compressor, 208-230/3/60, POE Oil, 3 Phase Motor with Internal Inherent Protection

Documents

There are no documents available.

Specifications

BrandCopeland
Height (In.)21.31
Hertz60 Hz
Length (In.)25.78
Weight (lbs)385
Width (In.)15.06
ManufacturerCopeland Canada
Application TemperatureMedium Temperature, Air Conditioning
RefrigerantR404A, R407A, R407C, R507
Capacity @ 0 F Evaporator Temperature48,001 to 60,000, 60,001 to 72,000
Capacity @ 20 F Evaporator Temperature72,001 to 96,000
Capacity @ 35 F Evaporator Temperature120,001 to 144,000
Capacity @ 45 F Evaporator Temperature120,001 to 144,000, 144,001 to 168,000
Compressor DesignSemi-Hermetic
Compressor Family3D Cylinder Discus
Compressor Locked Rotor Amps (High)215.00A
Initial Oil Charge (oz.)125
Liquid Line Size (In.)1-1/8 Sweat Stub
Motor Design3 Phase
Motor Overload ProtectionInternal Inherent
Mounting Height (In.)22.34
Mounting Length (In.)15
Mounting Width (In.)12
Oil or Lubricant TypePolyolester (POE)
Oil Recharge (oz.)115
R404A Capacity (Btu/Hr) @ 0 F Evaporator Temperature60,000
R404A Capacity (Btu/Hr) @ 20 F Evaporator Temperature85,000
R407A Capacity (Btu/Hr) @ 0 F Evaporator Temperature53200
R407A Capacity (Btu/Hr) @ 20 F Evaporator Temperature82500
R407A Capacity (Btu/Hr) @ 35 F Evaporator Temperature143500
R407A Capacity (Btu/Hr) @ 45 F Evaporator Temperature145,000
R407C Capacity (Btu/Hr) @ 0 F Evaporator Temperature53,000
R407C Capacity (Btu/Hr) @ 20 F Evaporator Temperature81100
R407C Capacity (Btu/Hr) @ 35 F Evaporator Temperature136,000
R407C Capacity (Btu/Hr) @ 45 F Evaporator Temperature140,000
R507 Capacity (Btu/Hr) @ 0 F Evaporator Temperature62,000
R507 Capacity (Btu/Hr) @ 20 F Evaporator Temperature87500
Suction Line Size (In.)1-3/8 Sweat Stub
Voltage (V)208-230/3
