Discontinued Model
Allied 3 Ton Gas/Electric 108Mbh/Bd/Hpec/575/3
Specification
BrandAllied Air
Manufacturer["Allied Air Enterprises"]
ModelKGB036S4DQ-J-FB277-ALD
Compressor DesignScroll
Voltage (V)575
RefrigerantR410A
Manufacturer NumberKGB036S4DQ-J-FB277
Nominal Capacity (Tons)3
Phase (1/3)3
AFUE Rating81
Compressor TypeScroll
Drain Connection (in)1
Energy Efficiency Rating (EER)12.3
Energy Efficiency Rating (SEER)14
Height (in)38.88
Maximum Fuse (Amps)15
Minimum Circuit Ampacity9
Weight (lbs)531
Width (in)47
Flow ConfigurationDownflow
Heat Exchanger MaterialAluminized Steel
Length (in)83.25
Baseweightlbs531
BlowertypePSC
CabinetmaterialHeavy Gauge Steel
Compressorlockedrotoramps27
Compressorratedloadamps3.6
CondenserstagesSingle
CoolingefficiencyStandard
Decibelleveldba74
Nominalcoolingcapacitytons3
UnittypePackaged Heat Pump
Documentation
Disclaimer
For professional use only. Refer to all information, warnings and instructions on Product and package labeling and accompanying documentation provided by the Product manufacturer. Product must be used in accordance with such labeling and documentation.
