Manufacturer["Allied Air Enterprises"]
Model7SCP18V36P-ALD
Compressor DesignBLDC Rotary
Voltage (V)208-230
RefrigerantR454B
Efficiency SEER219
Manufacturer Number7SCP18V36P
Nominal Capacity (Tons)3
Airflow (CFM)3330
Compressor Rated Load Amps (208/230V)16.5
Compressor TypeBLDC Rotary
Depth (in)19.875
Factory Charge (lbs)5.5625
Fan Motor Rated Output (Watts)200
Height (in)33.13
HSPF2 Rating10
Max Fuse Size / Fusible Max35
Maximum Line Set Length (ft)150
Minimum Circuit Ampacity24
Refrigerant Charge (lbs)5.5625
Refrigerant ControlElectronic Expansion Valve
Shipping Weight (lbs)190
Sound Pressure Level (dBA)57
Suction Line Size (in)0.875
Weight (lbs)157
Width (in)43.13
Heat/Cool FunctionHeating and Cooling
Standard Outdoor Cooling Temperature Range5 F to 115 F (-15 C to 46 C)
Fanmotorfullloadamps208230v1.5
