Manufacturer["FUJITSU GENERAL AMERICA INC"]
ModelADUH12KUAS-FUJ
RefrigerantR32
Capacity (BTU/Hr)12,000
Manufacturer NumberADUH12KUAS
Nominal Capacity (Tons)1
ZoningMulti-Zone
Cooling Airflow (H/M/L/SL)High 383, Med 353, Low 324, Quiet 283
Cooling Capacity (BTU/Hr)12,000
Depth (in)24.44 (24-7/16)
Drain Connection (in)1.25 (1-1/4)
Heating Airflow (H/M/L/SL, CFM)High 383, Med 353, Low 324, Quiet 283
Height (in)7.81 (7-13/16)
Max Fuse Size / Fusible Max250
Minimum Circuit Ampacity0.47/0.44
Minimum Outdoor Cooling Temperature-5 F (-21 C)
Outdoor Heating Temperature Range-15 to 75 F (-26 to 24 C)
Suction Line Size (in)0.38 (3/8)
Weight (lbs)37
Width (in)27.56 (27-9/16)
Fan TypeSirocco Fan
Heat/Cool FunctionHeating and Cooling
Indoor Unit StyleSlim Duct
Standard Outdoor Cooling Temperature Range-5 to 122 F (-21 to 50 C)
Frequency (Hz)60
CompatibleoutdoorunitsmultizoneAOUH18KWAS2, AOUH24KWAS3, AOUH36KWAS4, AOUH45KWAS5
Fanmotoroutput80
FanspeedsAuto, High, Med, Low, Quiet
Maximumcoolingairflowcfm383
Maximumheatingairflowcfm383
Minindoornoiseleveldba24
Powerfrequency60
Voltagev208-230
