Manufacturer["FUJITSU GENERAL AMERICA INC"]
ModelADUH09KUAS-FUJ
RefrigerantR32
Capacity (BTU/Hr)9,000
Manufacturer NumberADUH09KUAS
Nominal Capacity (Tons)0.75
ZoningMulti-Zone
Cooling Airflow (H/M/L/SL)High 353, Med 324, Low 294, Quiet 265
Cooling Capacity (BTU/Hr)9,000
Depth (in)24.44 (24-7/16)
Drain Connection (in)1.25 (1-1/4)
Heating Airflow (H/M/L/SL, CFM)High 353, Med 324, Low 294, Quiet 265
Height (in)7.81 (7-13/16)
Max Fuse Size / Fusible Max250
Minimum Circuit Ampacity0.40/0.38
Minimum Outdoor Cooling Temperature-5 F (-21 C)
Outdoor Heating Temperature Range-15 to 75 F (-26 to 24 C)
Suction Line Size (in)0.38 (3/8)
Weight (lbs)37
Width (in)27.56 (27-9/16)
Fan TypeSirocco Fan
Heat/Cool FunctionHeating and Cooling
Indoor Unit StyleSlim Duct
Standard Outdoor Cooling Temperature Range-5 to 122 F (-21 to 50 C)
Frequency (Hz)60
CompatibleoutdoorunitsmultizoneAOUH18KWAS2, AOUH24KWAS3, AOUH36KWAS4, AOUH45KWAS5
Fanmotoroutput80
FanspeedsAuto, High, Med, Low, Quiet
Maximumcoolingairflowcfm353
Maximumheatingairflowcfm353
Minindoornoiseleveldba24
Powerfrequency60
Voltagev208-230
