Manufacturer["FUJITSU GENERAL AMERICA INC"]
ModelASUH09KPAS-FUJ
Compressor DesignInverter Driven
RefrigerantR32
Capacity (BTU/Hr)9000 (Cooling) / 10000 (Heating)
Efficiency EER212.5
Efficiency SEER226
Manufacturer NumberASUH09KPAS
Nominal Capacity (Tons)0.75
ZoningSingle-Zone
Airflow (CFM)394
ColourWhite
Compressor TypeInverter Driven
Cooling Airflow (H/M/L/SL)394 / 318 / 247 / 153
Cooling Capacity (BTU/Hr)9000
Depth (in)8.75 (8-3/4)
Drain Connection (in)17/32
Heating Airflow (H/M/L/SL, CFM)430 / 336 / 265 / 188
Height (in)10.62 (10-5/8)
HSPF2 Rating10.8
Max Fuse Size / Fusible Max15
Minimum Circuit Ampacity9.7 A
Minimum Outdoor Cooling Temperature14°F (-10°C)
Outdoor Heating Temperature Range5 to 75°F (-15 to 24°C)
Sound Pressure Level (dBA)19-40 (Cooling) / 21-42 (Heating)
Suction Line Size (in)3/8
Weight (lbs)21 (9.5 kg)
Width (in)32.81 (32-13/16)
Fan TypeCross Flow Fan
Heat/Cool FunctionHeating and Cooling
Indoor Unit StyleWall Mount
Standard Outdoor Cooling Temperature Range14 to 122°F (-10 to 50°C)
Frequency (Hz)60
AirdirectioncontrolYes
CompatibleoutdoorunitssinglezoneAOUH09KPAS1
ControltypeHand Held Remote
EnclosurecolourWhite
EvaporatorfantypeBLDC Motor With Cross-Flow Fan
Fanmotoroutput30
Fanspeeds7 (Auto, High, Med-High, Med, Med-Low, Low, Quiet)
Heatingtemperaturerangef5 to 75°F (-15 to 24°C)
Maximumcoolingairflowcfm394
Maximumheatingairflowcfm430
Minindoornoiseleveldba19
Powerfrequency60
TemperaturecontrolYes
Voltagev208-230
