Manufacturer["Hisense HVAC"]
ModelAS-18U3RHB25E-HIS
Compressor DesignRotary
Voltage (V)208-230V
RefrigerantR32
Capacity (BTU/Hr)18000
Efficiency EER211.95
Efficiency SEER220
Manufacturer NumberAS-18U3RHB25E
Nominal Capacity (Tons)1.5
Airflow (CFM)647
ColourWhite
Compressor TypeRotary
Cooling Airflow (H/M/L/SL)647/603/521/466/400
Cooling Capacity (BTU/Hr)18000
Depth (in)9
Drain Connection (in)0.75
Height (in)12.7
HSPF2 Rating9.8
Max Fuse Size / Fusible Max20
Minimum Circuit Ampacity3
Minimum Outdoor Cooling Temperature5 F (-15 C)
Outdoor Heating Temperature Range-4 - 75 F (-20 - 24 C)
Sound Pressure Level (dBA)49/46/39/37/33
Weight (lbs)29
Width (in)42
Fan TypeCross Flow Fan
Heat/Cool FunctionHeating and Cooling
Indoor Unit StyleWall Mount
Motor TypeBLDC
Standard Outdoor Cooling Temperature Range5 - 118 F (-15 - 48 C)
Fan Motor TypeBLDC with Crossflow Fan
Frequency (Hz)60
AirfilterWashable
CompatibleoutdoorunitssinglezoneAO-18U3R26E2
ControltypeHand Held Remote
EnclosurecolourWhite
EvaporatorfantypeBLDC Motor With Cross-Flow Fan
Fanmotoroutput45
FanspeedsFour
Heatingoperatingtemperature-4 - 75 F (-20 - 24 C)
Heatingtemperaturerangef-79
Maximumcoolingairflowcfm647
Minindoornoiseleveldba33
Noiseleveldba33
Powerfrequency60
