Manufacturer["Hisense HVAC"]
ModelAS-12U3RHB25E-HIS
Compressor DesignRotary
Voltage (V)208-230V
RefrigerantR32
Capacity (BTU/Hr)12000
Efficiency EER210
Efficiency SEER220
Manufacturer NumberAS-12U3RHB25E
Nominal Capacity (Tons)1
Airflow (CFM)394
ColourWhite
Compressor TypeRotary
Cooling Airflow (H/M/L/SL)394/312/265/253/235
Cooling Capacity (BTU/Hr)12000
Depth (in)8.03
Drain Connection (in)0.75
Height (in)11.54
HSPF2 Rating9
Max Fuse Size / Fusible Max15
Minimum Circuit Ampacity3
Minimum Outdoor Cooling Temperature5 F (-15 C)
Outdoor Heating Temperature Range-4 - 75 F (-20 - 24 C)
Sound Pressure Level (dBA)46/40/32.5/30/28
Weight (lbs)21
Width (in)33.46
Fan TypeCross Flow Fan
Heat/Cool FunctionHeating and Cooling
Indoor Unit StyleWall Mount
Motor TypeBLDC
Standard Outdoor Cooling Temperature Range5 - 118 F (-15 - 48 C)
Fan Motor TypeBLDC with Crossflow Fan
Frequency (Hz)60
AirfilterWashable
CompatibleoutdoorunitssinglezoneAO-12U3R26E2
ControltypeHand Held Remote
EnclosurecolourWhite
EvaporatorfantypeBLDC Motor With Cross-Flow Fan
Fanmotoroutput25
FanspeedsFour
Heatingoperatingtemperature-4 - 75 F (-20 - 24 C)
Heatingtemperaturerangef-79
Maximumcoolingairflowcfm394
Minindoornoiseleveldba28
Powerfrequency60
