Discontinued Model
Magic Pak 1.5 Ton 11 EER Electric/Electric 5 kW Heat Packaged Unit | 208-230/1
Description
Read more
Specification
BrandMagicPak
Manufacturer["Allied Air Enterprises"]
Model5MCE4-11-181FP-ALD
Voltage (V)208-230/1
RefrigerantR410A
Manufacturer Number1.523008
Cooling Capacity (BTU/Hr)18000
Depth (in)21.5
Drain Connection (in)0.75 NPT
Energy Efficiency Rating (EER)11
Height (in)43-7/8
Maximum Fuse (Amps)30.00A @ 230 V
Sound Pressure Level (dBA)73
Weight (lbs)207
Width (in)28
Blower Motor DesignConstant Torque ECM
Frequency (Hz)60 Hz
Blowermotorratedloadampsat208230v1.00A
CabinetmaterialEmbossed Steel
CoiloptionsStandard
Compressorratedloadampsat208230v6.70A
CompressorstagesSingle Stage
Compressorwarrantyperiod5 Years
Fanmotorhorsepowerrating1/8
Fanmotorratedloadamps208230v0.90
Fanmotorratedloadampsat208230v0.90
Fanmotorrpm1125
Heatingcapacitykw5
Motorhorsepower1/3
Nominalcoolingcapacitytons1.5
Nominalfiltersizein18 X 20 X 1
Documentation
Disclaimer
For professional use only. Refer to all information, warnings and instructions on Product and package labeling and accompanying documentation provided by the Product manufacturer. Product must be used in accordance with such labeling and documentation.
