Discontinued Model
Magic Pak 1 Ton 11 EER Electric Cooling Packaged Unit with Coil Corrosion Protection | 208-230/1
Description
Read more
Specification
BrandMagicPak
Manufacturer["Allied Air Enterprises"]
Model0MCE4-11-121CP-ALD
Voltage (V)208-230/1
RefrigerantR410A
Manufacturer Number1.523026
Cooling Capacity (BTU/Hr)12000
Depth (in)21.5
Drain Connection (in)0.75 NPT
Energy Efficiency Rating (EER)11
Height (in)43-7/8
Maximum Fuse (Amps)15.00A @ 208 V
Sound Pressure Level (dBA)73
Weight (lbs)193
Width (in)28
Blower Motor DesignConstant Torque ECM
Frequency (Hz)60 Hz
Blowermotorratedloadampsat208230v0.30A
CabinetmaterialEmbossed Steel
CoiloptionsCoil Corrosion Protection
Compressorratedloadampsat208230v5.00A
CompressorstagesSingle Stage
Compressorwarrantyperiod5 Years
Fanmotorhorsepowerrating1/8
Fanmotorratedloadamps208230v0.90
Fanmotorratedloadampsat208230v0.90
Fanmotorrpm1125
Motorhorsepower1/3
Nominalcoolingcapacitytons1
Nominalfiltersizein18 X 20 X 1
