Discontinued Model
Magic Pak 2.5 Ton 11 EER Electric/Electric 5 kW Heat Packaged Unit with Coil Protection | 208-230/1
Description
Read more
Specification
BrandMagicPak
Manufacturer["Allied Air Enterprises"]
Model5MCE4-11-301CP-ALD
Voltage (V)208-230/1
RefrigerantR410A
Manufacturer Number1.523039
Cooling Capacity (BTU/Hr)30000
Depth (in)24.375
Drain Connection (in)0.75 NPT
Energy Efficiency Rating (EER)11
Height (in)55-7/8
Maximum Fuse (Amps)30.00A @ 230 V
Sound Pressure Level (dBA)79
Weight (lbs)256
Width (in)28
Blower Motor DesignConstant Torque ECM
Frequency (Hz)60 Hz
Blowermotorratedloadampsat208230v1.00A
CabinetmaterialEmbossed Steel
CoiloptionsCoil Corrosion Protection
Compressorratedloadampsat208230v13.40A
CompressorstagesSingle Stage
Compressorwarrantyperiod5 Years
Fanmotorhorsepowerrating1/4
Fanmotorratedloadamps208230v1.60
Fanmotorratedloadampsat208230v1.60
Fanmotorrpm1100
Heatingcapacitykw5
Motorhorsepower1/2
Nominalcoolingcapacitytons2.5
Nominalfiltersizein24 X 22 X 1
