Specification
BrandMarathon Motors
Manufacturer["Regal Beloit Canada"]
ModelX526-RCI
Voltage (V)575/3
Amperage2.70A
Manufacturer Number056T11O5309
RPM1140
Motor DesignSquirrel Cage Induction Run
Poles6
Weight (lbs)45
Motor Type["6.5\" Diameter Motors","Condenser Fan Motors"]
Package Contents(1) Shaft Slinger
Number of Speeds1
Bearing TypeBall
Body Diameter (in)6.48
Duty CycleContinuous
EnclosureOpen Air Over
Frequency (Hz)60 Hz
Horsepower Rating2
Motor Overload ProtectionAutomatic Thermal
NEMA Frame56Z
Number of Shafts1
RotationCW
Shaft Design["T","Flat"]
Shank / Shaft Length (in)5.06
