Specification
BrandMarathon Motors
Manufacturer["Regal Beloit Canada"]
ModelX502-RCI
Voltage (V)460/3, 208-230/3
Amperage4.00-4.20A, 2.10A
Manufacturer Number056T11O5302
RPM1140
Motor DesignSquirrel Cage Induction Run
Poles6
Weight (lbs)29
Motor Type["6.5\" Diameter Motors","Condenser Fan Motors"]
Package Contents(1) Shaft Slinger
Number of Speeds1
Bearing TypeBall
Body Diameter (in)6.48
Duty CycleContinuous
EnclosureOpen Air Over
Frequency (Hz)50/60 Hz
Horsepower Rating3/4
Motor Overload ProtectionAutomatic Lock Rotor Only
NEMA Frame56Y
Number of Shafts1
RotationCW
Shaft Design["Flat","T"]
Shank / Shaft Length (in)5.06
