Manufacturer["Samsung HVAC"]
ModelAR12DXFAMWKXCV-SAM
Compressor DesignInverter Driven, Twin BLDC Rotary
Voltage (V)208-230
RefrigerantR32
Capacity (BTU/Hr)12000
Efficiency EER213.25
Efficiency SEER224
Manufacturer NumberAR12DXFAMWKXCV
ZoningSingle-Zone
Airflow (CFM)1589
ColourWhite
Compressor Rated Load Amps (208/230V)9.2
Depth (in)11.25
Drain Connection (in)0.6875
Factory Charge (lbs)2.125
Fan Motor Rated Output (Watts)40
Height (in)21.5625
HSPF2 Rating9
Max Fuse Size / Fusible Max20
Outdoor Noise Level (dBA)46
Refrigerant ControlElectronic Expansion Valve
Suction Line Size (in)3/8
Weight (lbs)69.2
Width (in)31.125
Fan TypePropeller Fan
Heat/Cool FunctionHeating and Cooling
Standard Outdoor Cooling Temperature Range14 - 115 F (-10 - 46 C)
Fan Motor TypeBLDC With Axial Fan
MaterialGalvanized Steel
CabinetfinishBaked Powder Coated Paint
CoiltypeFin & Tube
CondensermotortypeBLDC with Axial Type Fan
Fanmotorfullloadamps208230v0.42
Heatingoperatingtemperature-5 - 75 F (-20.6 - 24 C)
