Specifications

• BrandDaikin
• Energy Efficiency Rating (EER)8.5 EER with FTKB12AXVJU
• Energy Efficiency Rating (SEER)17 SEER with FTKB12AXVJU, 17 to 17.99
• Minimum Circuit Ampacity7.70A
• Sound Pressure Level (dBA)48
• ManufacturerDaikin
• Capacity (Btu/Hr)12,000
• Heat/Cool FunctionCooling Only
• ZoningSingle Zone
• Height (In.)21-5/8
• Width (In.)25-15/16
• Depth (In.)10-3/4
• RefrigerantR410A
• DisclaimerFor professional use only. Refer to all information, warnings and instructions on product and package labeling and accompanying documentation provided by the product manufacturer. Product must be used in accordance with such labeling and documentation.
• Compatible Indoor Unit(s) - Wall MountFTKB12AXVJU
• Compressor DesignHermetically Sealed Swing
• Compressor Rated Load Amps @ 208/230 V7.50A
• Cooling Airflow H/M/L/SL (CFM)730
• Drain Connection (In.)3/4
• Fan Motor Full Load Amps @ 208/230 V0.19A
• Fan Motor Rated Output (Watts)41
• Hertz60 Hz
• Liquid Line Size (In.)1/4
• Maximum Fuse Amps15.00A
• Maximum Lineset Length (Ft)65.6
• Nominal Capacity (Tons)1
• Standard Outdoor Cooling Temperature Range50 to 115 F (10 to 46 C) Matched with FTKB12AXVJU
• Suction Line Size (In.)3/8
• Voltage (V)208-230/1
• Weight (lbs)57
