Specifications

• BrandSamsung
• Energy Efficiency Rating (EER)13.95 EER with AR09TSFYBWKNCV
• Energy Efficiency Rating (SEER)23 to 23.99, 23.5 SEER with AR09TSFYBWKNCV
• Liquid Line Size (In.)1/4 Flare
• Minimum Circuit Ampacity12.00A
• Sound Pressure Level (dBa)45
• ManufacturerSamsung HVAC
• Heat/Cool FunctionHeating and Cooling
• Nominal Capacity (Btu/Hr)9000
• ZoningSingle Zone
• Height (In.)21-9/16
• Width (In.)31-1/8
• Depth (In.)11-1/4
• RefrigerantR410A
• DisclaimerFor professional use only. Refer to all information, warnings and instructions on product and package labeling and accompanying documentation provided by the product manufacturer. Product must be used in accordance with such labeling and documentation.
• Compatible Indoor Unit(s) - Wall MountAR09TSFYBWKNCV
• Compressor DesignBLDC Rotary
• Compressor Rated Load Amps @ 208/230 V9.00A
• Cooling Airflow H/M/L/SL (CFM)300/335/353/371
• Drain Connection (In.)11/16 OD
• Heating Airflow L/M/H/Turbo (CFM)335/371/385/403
• Heating Seasonal Performance Factor (HSPF)10 +, 12.0 with AR09TSFYBWKNCV
• Hertz60 Hz
• Maximum Fuse Amps20.00A
• Maximum Lineset Length (Ft)66
• Nominal Capacity (Tons)3/4
• Outdoor Heating Temperature Range-5 to 75 F (-21 to 24 C) Matched with AR09TSFYBWKNCV
• Standard Outdoor Cooling Temperature Range14 to 115 F (-10 to 46 C) Matched with AR09TSFYBWKNCV
• Suction Line Size (In.)3/8 Flare
• Voltage (V)208-230/1
• Weight (lbs)69.9
